Neff U1421B2GB B1320W2GB Oven Hinges, Sold In Pairs, Genuine Neff Spares, Built In Oven Hinge For Early Models, Original Spare Parts
Pair of hinges to fit *NEFF integrated, built under and built in oven. If your oven door is not closing properly then it will almost certainly need two new hinges, it is good practice to change both hinges at the same time because if one has failed, then the other is usually weakened and prone to failure shortly after. TDSpares only supply the exact same original factory fitted hinges that were on your appliance when you bought it. So, you can have complete confidence in buying from us.
- SORRY NO LONGER AVAILABLE.
- Sold In Pairs
- For Main Oven Door (usually the larger lower oven on twin door models)
- These are original NEFF Spare Parts and not copies.
- Two screw fixing at one end.*
- *NOTE! - 2 versions of this hinge have be used in production, please compare your original hinges with the above images before ordering. The newer versions were fastened to the inside door frame via an extending side mounting plate. See alternatives tab below.
- Dimensions: L 219mm x W 20mm x H 21mm, bottom fixing hole centres 14mm, Distance from centre of the top fixing hole to the bottom is 205mm
- A tool for removing the Torx 'star' style screws (where fitted) can also be found here.
If you believe that these hinges may fit your model but do not see it listed above, then please contact us and provide your full make & model number (usually found on your instruction book or behind the door) and we will be happy to check for you. *TIP - take a snapshot of your rating plate with your digital camera or smartphone and send it to us using the attachment feature on the contact form.
Supplied by BOSCH NEFF SIEMENS
NEFF B1310B0GB/01 B1310N0GB/01 B1310N2GB/01 B1320N0GB/01 B1320N2GB/01 B1320N2GB/02 B1320N2GB/05 B1320S2GB/01 B1320S2GB/02 B1320W0GB/01 B1320W2GB/01 B1320W2GB/02 B1420B0GB/01 B1420B0GB/02 B1420B0GB/03 B1420B0GB/05 B1420N0/01 B1420N0/02 B1420N0/03 B1420S0/01 B1420S0/02 B1420W0GB/01 B1420W0GB/02 B1420W0GB/03 B1420W0GB/05 B1421B0GB/01 B1421B2GB/01 B1421B2GB/02 B1421S0GB/01 B1421S2GB/01 B1421S2GB/02 B1421W0GB/01 B1421W2GB/01 B1421W2GB/02 B1430B0GB/01 B1430B0GB/02 B1430B0GB/05 B1430C0GB/01 B1430C0GB/02 B1430K0GB/01 B1430K0GB/02 B1430K0GB/03 B1430U0GB/01 B1430U0GB/02 B1430V0GB/01 B1430V0GB/02 B1430W0GB/01 B1430W0GB/02 B1430W0GB/05 B1432A2GB/01 B1432A2GB/02 B1432B0GB/01 B1432B2GB/01 B1432B2GB/02 B1432S0GB/01 B1432S2GB/01 B1432S2GB/02 B1432W0GB/01 B1432W2GB/01 B1432W2GB/02 B1441B0GB/01 B1441B0GB/02 B1441B0GB/04 B1441B0GB/05 B1441W0GB/01 B1441W0GB/02 B1441W0GB/04 B1441W0GB/05 B1442N0FG/01 B1442N0FG/02 B1541S0/01 B1541W0/04 B1542B0GB/01 B1542B0GB/05 B1542S0GB/01 B1542S0GB/05 B1542W0GB/01 B1542W0GB/05 B1561B1GB/04 B1561N0/01 B1561N0/04 B1561W1GB/04 B1820W0GB/03 E1431N0/01 E1431N0/02 E1431N0/03 E1431N0/04 U1320B0GB/01 U1320N0GB/01 U1320N2GB/01 U1320N2GB/02 U1320W0GB/01 U1320W2GB/01 U1320W2GB/02 U1410B0GB/01 U1410B0GB/02 U1410B0GB/05 U1410B0GB/06 U1410W0GB/01 U1410W0GB/02 U1410W0GB/05 U1410W0GB/06 U1420B0GB/01 U1420B0GB/02 U1420B0GB/05 U1420C0GB/01 U1420H0GB/01 U1420K0GB/01 U1420U0GB/01 U1420V0GB/01 U1420W0GB/01 U1420W0GB/02 U1420W0GB/05 U1421B0GB/01 U1421B2GB/01 U1421B2GB/02 U1421S0GB/01 U1421S2GB/01 U1421S2GB/02 U1421W0GB/01 U1421W2GB/01 U1421W2GB/02 U1441B0GB/01 U1441S0GB/01 U1441W0GB/01 U1451B0GB/01 U1451B0GB/04 U1451B0GB/05 U1451S0GB/01 U1451S0GB/04 U1451S0GB/05 U1451W0GB/01 U1451W0GB/04 U1451W0GB/05 U1452B0GB/01 U1452B1GB/01 U1452B2GB/01 U1452N3GB/05 U1452S0GB/01 U1452S1GB/01 U1452S2GB/01 U1452W0GB/01 U1452W1GB/01 U1452W2GB/01 U1551B0GB/01 U1551W0GB/01 U1552B0GB/01 U1552B0GB/05 U1552W0GB/01 U1552W0GB/05 U1562B0GB/01 U1562B0GB/05 U1562B0GB00 U1562W0GB/01 U1562W0GB/05 U1562W0GB00
